Marine Rescue sMRT V100

    • 299 £
    • 2999 £

Description

The world’s most advanced alerting and tracking Personal Locator Beacon. The sMRT V100 & the sMRT V100X transmit a distress alert and position update via a combination of AIS and VHF DSC technologies in accordance with the latest international safety standards. This provides the best possible chance of survival in the event of a man overboard (MOB) situation. As soon as they hit the water, it automatically activates and sends an alert to all VHF DSC radios within range. The GPS position is then updated every 60 seconds via AIS, enabling exact position tracking.

Additional information

Weight 0.4 kg

WHY CHOOSE A sMRT V100?

  • 5 year battery life
  • 24/7 Monitoring
  • Activates automatically on inflation of lifejacket, immersion in water or manually
  • Indicates GPS position in less than 45 seconds
  • Updates GPS position via AIS every minute
  • Tracks multiple targets simultaneously
  • Individual MMSI identification
  • Designed to be integrated into the SOLAS approved sMRT PFD
  • Enables every vessel nearby to become a SAR asset
  • Works with existing VHF DSC and AIS equipment
  • 150 mile transmission range with worldwide satellite coverage
  • Optional recertification ensures optimum performance (recommended annually)

DESIGNED TO MEET NEW INTERNATIONAL SAFETY STANDARDS

*Dependent on weather conditions, quality and height of receiving antenna.

sMRT V100 Technical Information

GENERAL
  • Battery Type 9.0V 1500mAh Lithium Manganese Dioxide (LiMnO2)
  • Battery Life Minimum of 12 hours at -20°C.
  • Battery Shelf Life at +20°C 5 years
  • Operating Temperature -20° to +55°C (-4° to +131°F) as per IEC 60945
  • Storage Temperature -30° to +70°C (-22° to +158°F) as per IEC 60945
  • Dimensions 51mm W x 137mm H x 26mm D
  • Weight 168g
  • Durability IEC Standard 60945
  • Strobe Light 20 candela, 170 degree dispersion, flash rate once-per-sec
  • Environmental Resistance IP67
  • Mounting Options Designed to integrate with a SOLAS approved life jacket
  • Self ID ITU-R M.585 Compliant factory programmed freeform Maritime Identity with 972 prefix Compass Safe Distance 0.5m (1.5ft)
  • Alerting Radius Up to 75 mile range (from fixed wing aircraft)*
AIS/VHF TRANSMITTER PACKAGES
  • Antenna type
  • AIS Tx Power Output
  • VHF Transmission Frequencies
  • VHF DSC Tx Power Output
  • Signalling Type
CONTROLS AND OPERATION
  • Automatic Activation
  • Automatic Water Activation
  • Manual Activation
GPS RECEIVER
  • GPS Receiver Type
  • TTFF (Time to First Fix)
  • Subsequent GPS fixes
VHF DSC AND AIS ALERTS
  • AIS
  • Initial Open Loop DSC Alert
  • Subsequent Open Loop DSC Alerts
  • First DSC GPS data alert sent
  • APPROVALS
  • European Approvals
  • US Approvals

  • Vertically polarised
  • Nominal 1W EIRP
  • VHF DSC Channel 70: 156.525MHz
  • AIS Channel 1: 161.975MHz
  • AIS Channel 2: 162.025MHz
  • Nominal radiated power 500mW
  • AIS and VHF-DSC
  • On PFD inflation
  • After 2 seconds of water sensor immersion
  • Immediately following removal of activation tab
  • 56 channel
  • 45 seconds (typical) with nominal GPS signal levels -130dBm
  • Minimum of 6 per minute
  • Within 30 seconds of GPS position acquisition
  • 10 seconds after activation
  • Every 5 minutes for the first 30 minutes, every 10 minutes thereafter until VHF-DSC
  • acknowledgement or the battery expires.
  • Immediately after GPS position acquired
CE approved EN 303 098 V1.2.1 & draft EN 303 132 FCC 2ABF7SMRTV100 RTCM STANDARD 11901.1

WHY CHOOSE A sMRT V100x?

  • Monitor your crew 24/7
  • Activates automatically on inflation/immersion in water or manually
  • Indicates GPS position in less than 45s
  • Designed to be integrated into a SOLAS approved sMRT PFD
  • Enables every vessel nearby to become a SAR asset
  • Works with existing VHF DSC and AIS equipment
  • 150 mile transmission range with worldwide satellite coverage
  • Annual recertification ensures optimum performance
  • Zone 1 IECEx rated
  • Updates GPS position via AIS every minute
  • Tracks multiple targets simultaneously
  • Individual MMSI identification

sMRT V100x Technical Information

GENERAL
  • Battery Type 9.0V 1500mAh Lithium Manganese Dioxide (LiMnO2)
  • Battery Life Minimum of 12 hours at -20°C
  • Battery Shelf Life at +20°C 5 years
  • Operating Temperature -20° to +55°C (-4° to +131°F) as per IEC 60945
  • Storage Temperature -30° to +70°C (-22° to +158°F) as per IEC 60945
  • Dimensions 51mm W x 137mm H x 26mm D
  • Weight 212g
  • Durability IEC Standard 60945
  • Strobe Light 20 candela, 170 degree dispersion, flash rate once-per-sec
  • Environmental Resistance IP67
  • Mounting Options Designed to integrate with a SOLAS approved life jacket
  • Self ID ITU-R M.585 Compliant factory programmed freeform Maritime Identity with 972 prefix
  • Compass Safe Distance 0.5m (1.5ft)
  • Alerting Radius Up to 75 mile range (from fixed wing aircraft)*
AIS/VHF TRANSMITTER PACKAGES
  • Antenna type Vertically polarised
  • AIS Tx Power Output Nominal 1W EIRP
  • VHF Transmission Frequencies VHF DSC Channel 70: 156.525MHz
  • AIS Channel 1: 161.975MHz
  • AIS Channel 2: 162.025MHz
  • VHF DSC Tx Power Output Nominal radiated power 500mW
  • Signalling Type AIS and VHF-DSC
CONTROLS AND OPERATION
  • Automatic Activation On PFD inflation
  • Automatic Water Activation After 2 seconds of water sensor immersion
  • Manual Activation Immediately following removal of activation tab
GPS RECEIVER
  • GPS Receiver Type 56 channel
  • TTFF (Time to First Fix) 45 seconds (typical) with nominal GPS signal levels -130dBm
  • Subsequent GPS fixes Every five minutes for 30 mins; then every 10 mins until switched off or battery expires
VHF DSC AND AIS ALERTS
  • AIS Within 30 seconds of GPS position acquisition
  • Initial Open Loop DSC Alert 10 seconds after activation
  • Subsequent Open Loop DSC Alerts Every 5 minutes for the first 30 minutes, every 10 minutes thereafter until VHF-DSC acknowledgement or the battery expires.
  • First DSC GPS data alert sent Immediately after GPS position acquired
APPROVALS
  • European Approvals CE approved
  • EN 303 098 V1.2.1 & draft EN 303 132
  • US Approvals FCC 2ABF7SMRTV100
  • RTCM STANDARD 11901.1
  • ATEX/IECEx CERTIFICATION
  • ATEX/IECEx Classification Ex ib IIB Gb
  • ATEX Certificate Number TRAC13ATEX0032X
  • IECEx Certificate Number IECEX TRC 13.0012X
  • * Expected range derived from sea trials. Actual alerting range dependent on sea state, atmospheric conditions and height/altitude of receiving antenna.
